Front drum hydraulic winch 15 kN capacity
- paklausti apie kainą
-
paklauskite apie produktą
-
rekomenduoti draugui
Aprašymas
Performance
Max pull 15 kN
Max speed 70 m/min
Speed at max pull 25 m/min
Characteristics
Drum dimensions ø 350 x 620 mm
Drum capacity 400 m rope Ø 12 mm
Weight without rope 1260 kg
Engine
Diesel (25 hp) 19 kW
Cooling Liquid
Emission standard - (UE)2016/1628 Stage V
Standard features
• 1 hydraulic circuit with negative brake system
• 1 dynamometer for direct reading of pulling value with load-limiter device
• 300 m rope HMPE Ø 12 mm • Remote control unit c/w console 5 m cable
• Front stabilizer jack
• Back support by adjustable mechanical sprag
• Metallic cover can be opened on three sides
• On board toolbox
• Road trailer kit 1350 kg capacity with height adjustable drawbars and jockey wheel
• Upper lifting attachment point balanced type and anchoring attachments
Optional equipment
04-PW Radio control unit
13-PW Pre-heater (up to -30°C)
30-PW Spare wheel
34-PW Pressure roller on the drum
